BIBS manifold block

Divex product motif logo.jpg

The JFD BIBS manifold block assembly is available in several configurations; 2, 3 and 4 point pistons.

All are assembled and include the female quick disconnects and blanking plugs.

BIBS manifold block BIBS manifold block BIBS manifold block BIBS manifold block BIBS manifold block

View full image

BIBS Manifold Block 1 - Prod.jpg

View full image

BIBS Manifold Block 2 - Prod.jpg

View full image

BIBS Manifold Block 3 - Prod.jpg

View full image

BIBS Manifold Block 4 - Prod.jpg

View full image

BIBS Manifold Block 5 - Prod.jpg

Item Order Code

BIBS manifold block, 2-man, inlet

DC1752007

BIBS manifold block, 2-man, exhaust

DC1752008

BIBS manifold block, 3-man, inlet

E16589

BIBS manifold block, 3-man, exhaust

E16588

BIBS manifold block, 4-man, inlet

DC0345

BIBS manifold block, 4-man, exhaust

DC0346
Document Document type Download
4-man BIBS manifold assembly, inlet, DDC Drawing

DC0345S1 R3

4-man BIBS manifold assembly, outlet, DDC Drawing

DC0346S1 R3

BIBS inlet, 2 port assembly Drawing

DC1752007S1 R0

BIBS exhaust assembly, HLB100 Drawing

DC1752008S1 R1
