Bauer Poseidon PE TE

The PE200 / 250 / 300 TE models offer the optimum price vs performance ratio. Due to their compact construction, the units are easy to transport and to load into vehicles.

The oil pump allow inclinations up to 15^o, making these Bauer Poseidon PE200 / 250 / 300 TE compressors most suitable for use on board of ships.

Bauer Poseidon PE TE compressor

View full image

PE 250 TE II - Prod.jpg

1 225 bar / 330 bar alternatively. Optional: available with two pressures: 330 / 225 bar
2 Cylinder filling from 0 to 200 bar. Filling rate for 1 l cylinder capacity


Max. 330 bar¹
Model	PE200-TE	PE 250-TE	PE 300-TE
Drive	3-phase	3-phase	3-phase
FAD l/min²	200	250	300
RPM min^-1	1250	1450	1800
Filling rate min²	1,0	0,8	0,7
Drive kW	4,0	5,5	7,5
Drive HP	5,5	7,5	10,0
Purification system TRIPLEX®	P21	P21 / P31	P21 / P31 / P42
Dimensions L x W x H (approx cm)	110 x 50 x 57	110 x 50 x 57	110 x 52 x 57
Weight net. (approx kg)	120	130	140
Order code	PE200-TE	PE 250-TE	PE 300-TE


Model	PE250 HE	PE 300 HE
Automation options
Compressor control	Standard scope of supply	Standard scope of supply
Final pressure shut-off	Standard scope of supply	Standard scope of supply
Automatic condensate drain	Standard scope of supply	Standard scope of supply
Main cable and motor protection switch	Standard scope of supply	Standard scope of supply
Air purification options
Purification system P31	Standard scope of supply	Standard scope of supply
Purification system P42	Optional	Optional
B-Timer	Optional	Optional
Securus	Optional	Optional
Air distribution options
2 filling devices	Optional	Optional
Filling panel with 4 direct connections	Optional	Optional
Filling panel with 4 hose connections	Optional	Optional
225 or 330 bar version alternatively	Standard scope of supply	Standard scope of supply
225 and 330 bar	Optional	Optional

Item	Order Code
Bauer Poseidon PE200 TE compressor	PE200 TE
Bauer Poseidon PE250 TE compressor	PE250 TE
Bauer Poseidon PE300 TE compressor	PE300 TE

Document	Document Type	Download
Bauer Poseidon PE TE compressor	Datasheet	BAK-MDS-704 R1
